AT-XC
SHORT ACTION 6.5 CREEDMOOR /.308 WIN
COMPETITION RIFLE
The product of continuous development, next generation Accuracy International high performance, low profile AT-XC rifles feature cross-platform design enhancements to match the demands of sporting communities worldwide.
AT-XC A BORN COMPETITOR
LOW PROFILE, HIGH SPEC.
The non-bonded barrelled short action is bolted into a low profile chassis to minimise height over bore. The slick action builds trust and confidence in its capabilities.
PERFECT BALANCE
With a cut-rifled competition barrel manufactured by AI in the UK and central point of balance delivering linear recoil and rapid setup, the AT-XC is a reliable platform for accuracy at speed.
AI QUALITY
The AT-XC Comp/Pro model comes complete with all the accessories configured for the perfect Factory / Limited Div rifle. AI accuracy, repeatability and reliability naturally come as standard.
AT-XC STANDARD MODEL
Fixed stock with removeable interface for folding hinge accessory. Long bridge available as factory option
| CALIBRE | BBL LENGTH | MUZZLE THREAD | MUZZLE BRAKE | TWIST RATE |
|---|---|---|---|---|
| 6.5 Creedmoor | 24” (610 mm) | 5/8” x 24 UNEF | NONE | 1 IN 8 |
| 6.5 Creedmoor | 26” (660 mm) | 18 x 1.5 mm | AI tactical muzzle brake | 1 IN 8 |
| .308 WIN | 20” 508 mm) | 5/8” x 24 UNEF | NONE | 1 IN 10 |
| .308 WIN | 20” (508 mm) | 18 x 1.5 mm | AI tactical muzzle brake | 1 IN 10 |
| .308 WIN | 24” (610 mm) | 5/8” x 24 UNEF | NONE | 1 IN 10 |
| .308 WIN | 24” (610 mm) | 18 x 1.5 mm | AI tactical muzzle brake | 1 IN 10 |
| .308 WIN | 26” (660 mm) | 5/8” x 24 UNEF | NONE | 1 IN 10 |
| .308 WIN | 26” (660 mm) | 18 x 1.5 mm | AI tactical muzzle brake | 1 IN 10 |
AT-XC COMP/PRO MODEL
Includes long bridge, folding hinge, rear grip and external weights
| CALIBRE | BBL LENGTH | MUZZLE THREAD | MUZZLE BRAKE | TWIST RATE |
|---|---|---|---|---|
| 6.5 Creedmoor | 24” (610 mm) | 5/8” x 24 UNEF | NONE | 1 IN 8 |
| 6.5 Creedmoor | 26” (660 mm) | 18 x 1.5 mm | AI tactical muzzle brake | 1 IN 8 |
| .308 WIN | 24” (610 mm) | 5/8” x 24 UNEF | NONE | 1 IN 10 |
| .308 WIN | 26” (660 mm) | 18 x 1.5 mm | AI tactical muzzle brake | 1 IN 10 |
AT-XC FEATURES
List of Services
-
BUTT PADSHOW ME List Item 1
Target adjustable buttpad and length of pull: Min 321mm (12.6”) with a total range of 55mm (2.15”) in 5.5mm (0.215”) increments. Additional accessory butt spacers (standard or weighted) also available
-
CHEEKPIECESHOW ME List Item 2
Toolless quick adjustable cheekpiece: Height range: 24.5mm (0.96” in 3.5mm (0.14”) increments. A hex key for barrel change etc.) is conveniently stored beneath
-
REAR GRIPItem Link List Item 3
Rail mounted rear grip. Included on the Comp/Pro and available as an accessory for the Standard model. A quick adjust butt spike accessory is also available
-
FOLDING STOCKSHOW ME List Item 4
Included on Comp/Pro model, the rigid and stable right folding stock locks securely over the bolt and reduces overall length by 225 mm. Stock hinge accessory available for fixed stock Standard model
-
SLING POINTSItem Link
Three flush cup style points, two on rear end and one on side
-
PISTOL GRIPItem Link
Rubber AR style replaceable pistol grip
-
SAFETYSHOW ME
Three position safety catch on the bolt shroud:
Locked (bolt cannot be lifted)
Safe (bolt can be lifted)
Fire (firing pin engaged)
-
TRIGGERItem Link
Choice of AI standard or XTSP AI competition trigger. Two stage, adjustable for reach. Easily removable (two socket head screws) for cleaning
-
BOLTItem Link
Next generation with enhanced features, 6 lug, 60° bolt with bigger bolt handle and AI combat proven leaf spring extractor
List of Services
-
MAGAZINESHOW ME List Item 1
10 round double stack magazine. Slim profile mag catch for ambidextrous removal. Cut out magazine port on the left side for ease of insertion
-
ACTIONItem Link List Item 2
Next generation action with enhanced features, 3 position safety catch on bolt shroud, 6 lug, 60 deg. dynamic bolt lift and enlarged bolt handle
-
QUICKLOCItem Link List Item 3
AI’s patented system for barrel removal and refit including calibre/length change in minutes using the hex key stored under the cheekpiece.
-
TRIPOD MOUNTItem Link List Item 4
The flat bottomed forend features an integral RRS (Arca-Swiss style) tripod mounting rail
-
BARRIER SUPPORTItem Link
The lower chassis front face is machined to provide a rugged barricade support
-
FORENDItem Link
Low profile single plane forend 397mm (15.63”) to fit barrels with a minimum length of 508mm (20”) and maximum diameter of 31mm (1.22”). Integral RRS spec rail interface Length: 445mm (17.5”), KeySlot™ mounting system.
-
BARRELSItem Link
AI profile and cut-rifled competition grade barrels manufactured in England by AI UK
Twist rates;
.308 1 in 10
6.5CM 1 in 8
-
MUZZLE BRAKEItem Link
For barrels with 18 x 1.5 mm muzzle thread, the AI double chamber tactical muzzle brake reduces recoil, muzzle flash and dust eruption.
-
CHASSISItem Link
7075 aluminium chassis with superior AI KeySlot™ mounting system, featuring
20 MOA Action Rail, and AI repeatable Quickloc barrel change system
AT-XC ACCESSORIES
CALIBRES
.308 Winchester (short action)
6.5 Creedmoor (short action)
WEIGHT
With standard rail setup, empty magazine, no scope, 24” barrel, tactical muzzle brake: 6.2 kg
DIMENSIONS
With 24” barrel & tactical muzzle brake
Full length:
1155 mm x 180 mm x 100 mm
Stock folded:
940 mm x 180 mm x 105 mm
BARREL OPTIONS
• 20” or 24” plain or threaded barrel for AI muzzle brake
• 26” threaded barrel for AI muzzle brake 1 in 12 twist
FOREND BRIDGES
Short or long forend bridges easily attach to the forend interface, adding additional space for KeySlot™ rails and accessories whilst protecting the barrel
FOLDING STOCK HINGE
Replaces static interface to create a folding chassis
WEIGHTS
Internal, external and stackable .227 kg (½ lb) weights to reduce recoil and increase width for more contact / stability on a bag
AT-XC COLOURS
RED
BLACK
SAGE GREEN
DARK EARTH
AT-XC SPECIFICATION
CALIBREs
6.5 Creedmoor | .308 WIN multi calibre
AT-XC STANDARD
Fixed stock with interface for folding hinge accessory. Long forend bridge is a factory option
6.5 Creedmoor barrels
24", 5/8"x24 UNEF muzzle thread
26" 18x1.5 mm muzzle thread + AI muzzle brake
.308 WIN barrels
20", 24"or 26", 5/8"x24 UNEF muzzle thread
20", 24"or 26", 18x1.5 mm thread + AI muzzle brake
AT-XC COMP/PRO
Includes long bridge, folding hinge, rear grip and external weights
6.5 Creedmoor barrels
24" 5/8"x24 UNEF muzzle thread
26" 18x1.5 mm muzzle thread + AI muzzle brake
.308 WIN barrels
24"or 26", 5/8"x24 UNEF muzzle thread
24"or 26", 18x1.5 mm thread+ AI muzzle brake
FEATURES
• Right side folding stock over bolt (Comp/Pro)
• Toolless, quick adjust cheekpiece
• Toolless, quick adjust buttpad with spacers
• LOP adjustment 55mm (excluding spacers)
• Rear grip - rail mounted (Comp/Pro)
• Rubber AR style changeable pistol grip
• Flush cup sling attachment points
• 20 MOA action rail
• Oversize bolt handle
• User manual
• 1 x 10 round double stack CIP magazine
WEIGHT / LENGTH
Weight with 24" .308 barrel and AI muzzle brake: 6.28 kg
Full length: 1209mm
Stock folded: 985mm
ACCESSORIES
• STANAG 4694 / Mil std 1913 accessory rails to attach to AI’s patented KeySlot™ mounting system
• AI Bipod and mounts for other bipod brands
• Quick adjust butt spike
• Suppressor
• Slings
• Transit cases
• Cleaning kits
AT-XC SNAPSHOTS
Click for a bigger pic...
