AXSR MIL
LONG ACTION MULTI CAL RIFLE
The latest in a long and distinguished line of combat proven rifles, the long action AXSR multi calibre rifle system is available preconfigured in one of four calibres with either KeySlot or M-LOK forend accessory mounting system.
Armed with an AI calibre conversion kit comprising barrel, bolt and magazine a user can reconfigure the rifle in minutes without compromising accuracy, simply by using the hex key handily stored under the cheekpiece.
AXSR MIL FOR MILITARY AND LAW ENFORCEMENT
POWER TO COMMAND
With a cut-rifled barrel manufactured by AI in the UK and a central point of balance delivering linear recoil and rapid setup, the AXSR is a rigid and reliable platform for accuracy at speed.
WITHOUT COMPROMISE
The non- bonded barreled long action is bolted into the aluminium chassis, the slick action builds confidence and trust in the platform's capabilities.
CRITICAL PERFORMANCE
The multi cal AXSR comes complete with all the options and rapid adaptability required for the perfect sniper rifle.
AXSR MIL THE PROFESSIONALs CHOICE
| CALIBRE | BBL LENGTHS | MUZZLE THREAD | MUZZLE BRAKE | MOUNTING SYSTEM |
|---|---|---|---|---|
| 6.5 Creedmoor | 20" | 24” | 26" | 3/4" x 24, 3/4"x24 BN | NONE / B&T AG AI SPEC | KeySlot / M-LOK |
| 508mm | 610mm | 660mm | ||||
| .308 WIN | 20" | 24" | 26" | 3/4"x 24, 3/4"x 24BN | NONE / B&T AG AI SPEC | KeySlot / M-LOK |
| 508mm | 610mm | 660mm | ||||
| .300 WIN MAG | 20" | 24” | 26" | 3/4"x 24, 3/4"x 24BN | NONE / B&T AG AI SPEC | KeySlot / M-LOK |
| 508mm | 610mm | 660mm | ||||
| .338 LAP MAG | 27" | 3/4"x 24, 3/4"x 24BN | NONE / B&T AG AI SPEC | KeySlot / M-LOK |
| 686mm |
Additional calibres and barrel lengths available upon request
M-LOK OR KEYSLOTAXSR MIL
AXSR MIL FEATURES
List of Services
-
BUTT PADSHOW ME List Item 1
Toolless, quick adjust butt pad and Length of Pull: Min 321mm (12.6") with a total range of 55mm (2.15") in 3.2mm (0.12") increments
-
CHEEKPIECESHOW ME List Item 2
Height adjustable range: 22mm (0.86") in 3.2mm (0.12") increments. A hex key for barrel change etc. is conveniently stored beneath
-
REAR GRIPItem Link List Item 3
Rail mounted rear grip. A quick adjust butt spike is also available as an accessory
-
FOLDING HINGESHOW ME List Item 4
The rigid and stable right folding hinge locks securely over the bolt. Reduces overall length for shorter profile during transportation
-
SLING POINTSItem Link
Six flush cup style points, three on rear end, one on chassis and two repositional on each side of forend tube
-
PISTOL GRIPItem Link
Rubber AR style replaceable pistol grip
-
SAFETYSHOW ME
Two position ambidextrous safety catch:
S = Safe | F = Fire
-
TRIGGERItem Link
AI standard trigger. Two stage, adjustable for reach and weight between 1.5 Kg and 2 Kg. Easily removable (two socket head screws) for cleaning
-
BOLTItem Link
Maraging steel bolt head, 6 lug, 60° bolt and AI combat proven leaf spring extractor
List of Services
-
MAGAZINESHOW ME List Item 1
10 round double stack magazine. Slim profile mag catch for ambidextrous removal. Cut out magazine port on the left side for ease of insertion
-
ACTIONItem Link List Item 2
Proofed EN24T steel action and bolt body bolted to the aluminium chassis with 5 action screws. Action rail and forend rail 30/20 MOA STANAG 4694 / Mil Std for use with in-line Night vision or thermal scopes.
-
QUICKLOCItem Link List Item 3
AI’s patented system for barrel removal and refit including calibre/length change in minutes using the hex key stored under the cheekpiece.
-
TRIPOD MOUNTItem Link List Item 4
The flat bottomed forend grip and forend tube feature RRS integral (Arca-Swiss style) tripod mounting rails
-
BARRIER SUPPORTSItem Link
The stepped front face of the forend grip is machined to provide two rugged barricade supports
-
FORENDItem Link
The free floating octagonal forend tube is available with 16" 30 / 20 MOA or 13" 20 MOA rail with a choice of either KeySlot™ or M-LOK mounting system
-
BARRELSItem Link
AI profile and cut-rifled barrels manufactured in England by AI UK
-
MUZZLE BRAKEItem Link
The B&T AG muzzle brake designed for use with the B&T AG suppressor
-
CALIBRE KITSItem Link
Calibre kits comprising barrel, bolt and magazine for 6.5 Creedmoor, .308 Win, .300 Win Mag and .338 Lap Mag are available separately. A choice of barrel lengths for each calibre are also offered
AXSR MIL COLOURS
BLACK
SAGE GREEN
DARK EARTH
AXSR MIL SPECIFICATION
CALIBREs
6.5 Creedmoor | .308 Win
.300 Win Mag | .338 Lap Mag
WEIGHT
With B&T AG muzzle brake, empty magazine, standard accessory rails, rear grip
27" .338 Lap Mag barrel: 7.39 kg
DIMENSIONS
With 27” barrel & B&T AG muzzle brake
Full length: 1265 mm
Stock folded: 1050 mm
BARREL OPTIONS
6.5 Creedmoor 1:8 twist
20" (508mm), 24" (610mm), 26" (660mm)
.308 Win 1:10 twist
20" (508mm), 24" (610mm), 26" (660mm)
.300 Win Mag 1:11 twist
20" (508mm), 24" (610mm), 26" (660mm)
.338 Lap Mag
1:9.35 twist,
27" (686mm)
Muzzle thread options (all barrels)
3/4"x 24 muzzle thread/no muzzle brake or 3/4"x 24BN/B&T AG AI spec. muzzle brake
Other calibres/barrel lengths available on request
BASE MODEL
• Right side folding stock over bolt
• Toolless, quick adjust cheekpiece
• Toolless, quick adjust buttpad with spacers
• LOP adjustment 55 mm
• Rear grip (rail mounted)
• KeySlot™ or M-LOK forend mounting system with integral RRS spec. rail interface and machined barrier support
• Rubber AR style changeable pistol grip
• Flush cup sling attachment points
• 20/30 MOA STANAG 4694 / Mil Std 1913 action rail and forend rail
• B&T AG AI spec muzzle brake for use with B&T AG suppressor
• 1 x 140 mm plain accessory rail
• 2 x 80 mm flush cup accessory rails
• User manual
• 1 x 10 round double stack CIP magazine
ACCESSORIES
• STANAG 4694 / Mil std 1913 accessory rails to attach to AI’s KeySlot™ or M-LOK mounting system
• AI Bipod and mounts for other bipod brands
• Quick adjust butt spike
• Suppressor
• Slings
• Transit cases
• Cleaning kits
