AXSR
LONG ACTION MULTI CAL RIFLE
The next generation Accuracy International high performance, long action AXSR multi calibre rifle system features cross-platform enhancements to match the demands of sporting communities worldwide. Available preconfigured in one of four calibres and easily converted to others in minutes.
AXSR A RELIABLE COMPETITOR
high performance
The non-bonded barrelled long action is bolted into an aluminium chassis. With RRS spec (ARCA Swiss compatible) rail interface forend for tripod mounting. The slick action builds trust and confidence in its capabilities.
PERFECT BALANCE
With a cut-rifled barrel manufactured by AI in the UK and central point of balance delivering linear recoil and rapid setup, the AXSR is a reliable platform for accuracy at speed.
AI QUALITY
The AXSR comes complete with all the options and accessories configured for the perfect rifle. AI accuracy, repeatability and reliability naturally come as standard.
AXSR THE SPORTING CHOICE
| CALIBRE | BBL LENGTHS | MUZZLE THREAD | MUZZLE BRAKE |
|---|---|---|---|
| 6.5 Creedmoor | 24" / 26" (610mm / 660mm) | 3/4 x 24BN | B&T AG AI spec. |
| .308 WIN | 26" (660mm) | 3/4 x 24BN | B&T AG AI spec. |
| .300 Win Mag | 26" (660mm) | 3/4 x 24BN | B&T AG AI spec. |
| .338 LAP MAG | 27" (686mm) | 3/4 x 24BN | B&T AG AI spec. |
AXSR FEATURES
List of Services
-
BUTT PADSHOW ME List Item 1
Toolless Target adjustable buttpad. Min 321mm (12.6") with a total range of 55mm (2.15") in 3.2mm (0.12") increments
-
CHEEKPIECESHOW ME List Item 2
Height adjustable range: 22mm (0.86") in 3.22mm (0.12") increments.
A hex key for barrel change etc. is convenientLy stored beneath
-
REAR GRIPItem Link List Item 3
Rail mounted rear grip. A quick adjust butt spike is also available as an accessory
-
FOLDING STOCKSHOW ME List Item 4
The rigid and stable right folding stock locks securely over the bolt. Reduces overall length by 215 mm for transportation
-
SLING POINTSItem Link
Six flush cup style points, three on rear end, one on chassis and two repositional on each side of KeySlot™ forend tube
-
PISTOL GRIPItem Link
Rubber AR style replaceable pistol grip
-
SAFETYSHOW ME
Two position ambidextrous safety catch:
S = Safe | F = Fire
-
TRIGGERItem Link
AI standard trigger. Two stage, adjustable for reach and weight between 1.5 and 2Kg. Easily removable (two socket head screws) for cleaning
-
BOLTItem Link
6 lug, 60° bolt with AI combat proven leaf spring extractor
List of Services
-
MAGAZINESHOW ME List Item 1
10 round double stack magazine. Slim profile mag catch for ambidextrous removal. Cut out magazine port on the left side for ease of insertion
-
ACTIONItem Link List Item 2
Proofed EN24T steel action and bolt body with maraging steel bolt head and lock ring 6 lug 60' dynamic bolt lift. Action rail and forend rail 30 MOA / STANAG 4694 / Mil Std. 1913 Action bolted to the aluminium chassis with 5 action screws
-
QUICKLOCItem Link List Item 3
AI’s patented system for barrel removal and refit including calibre/length change in minutes using the hex key stored under the cheekpiece
-
TRIPOD MOUNTItem Link List Item 4
The flat bottomed forend grip and forend tube feature integral RRS (Arca-Swiss style) tripod mounting rails
-
BARRIER SUPPORTSItem Link
The stepped front face of the forend grip is machined to provide two rugged barricade supports
-
FORENDItem Link
The free floating 16" octagonal forend tube with full length 30 MOA STANAG 4694 / Mil Std 1913 rail features AI's patented KeySlot™ mounting system to take a wide range of accessories
-
BARRELSItem Link
AI profile and cut-rifled competition grade barrels manufactured in England by AI UK
-
MUZZLE BRAKEItem Link
The B&T AG muzzle brake reduces recoil, muzzle flash and dust eruption. Designed to be used with the B&T AG suppressor
-
CALIBRE KITSItem Link
Calibre kits comprising barrel, bolt and magazine for 6.5 Creedmoor, .308 Win, .300 Win Mag and .338 Lap Mag are available separately. A choice of barrel lengths for each calibre are also offered
AXSR COLOURS
BLACK
SAGE GREEN
DARK EARTH
AXSR SPECIFICATION
CALIBREs/BBL LENGTH
6.5 Creedmoor / 24", 26"
.308 Win / 26"
.300 Win Mag / 26"
.338 Lap Mag / 27"
WEIGHT/LENGTH
Weight with B&T AG muzzle brake, rear grip, empty magazine, standard accessory rails, no scope, no bipod, 27" .338 barrel: 7.39 kg
Length: 1265 mm (1050 mm folded)
FEATURES
• Right side folding stock over bolt
• Toolless, quick adjust cheekpiece
• Toolless, quick adjust buttpad with spacers
• LOP adjustment 55 mm (excluding spacers)
• Rear grip (rail mounted)
• Rubber AR style changeable pistol grip
• Flush cup sling attachment points
• 30 MOA STANAG 4694 /
Mil Std 1913 action rail and forend rail
• B&T AG muzzle brake
• 1 x 140 mm plain accessory rail
• 2 x 80 mm flush cup accessory rails
• User manual
• 1 x 10 round double stack CIP magazine
ACCESSORIES
• STANAG 4694 / Mil std 1913 accessory rails to attach to AI’s KeySlot™ mounting system
• AI Bipod and mounts for other bipod brands
• Quick adjust butt spike
• Suppressor
• Slings
• Transit cases
• Cleaning kits
